1. Description

When using the mvn archetype:generate command to generate a web project, you need to use a special archetype. This archetype, which specifically generates the skeleton of a web project, can refer to the official website to see its usage:

Parameters archetypeGroupId, archetypeArtifactId, archetypeVersion are used to specify the coordinates of the currently used maven-archetype-webapp. And in the previous chapter in the packaging jar: groupld, artfactld, version means the coordinates have the same meaning:

  • archetypeGroupId: The reverse order of the company or organization domain name, usually with the project name
    • For example: com.baidu.maven, positive sequence: domain name like maven.baidu.com, the domain name you know is com
  • archetypeArtifactId: The name of the module, which will be used as the project name of the Maven project in the future
  • archetypeVersion: The version number of the module, set according to your needs
    • For example: SNAPSHOT indicates the snapshot version, which is in the process of iteration, and the unstable version. If you don’t choose, Maven will default to this.
    • For example: RELEASE means the official release

2. Operation

Note: Similarly, if you want to execute the plugin in Maven, you need to be in the path of the pom.xml file.

Note: It is impossible to create multiple pom.xml files in a Maven project/module, that is to say, it cannot be created in an existing Maven In the project/module of strong>, if you create a project/module of Maven, you must create a new project/module of Maven in a new folder

If you execute the mvn archetype:generate command in the directory of the previous project, Maven will report an error: Cannot create other projects under a non-pom project. So don’t create a new project in the project just created, please go back to the root directory of the workspace to operate.

Here we create a new Maven project/module in E:\Maven_workspane\spaceVideo, named: pro02-maven-web

Enter the E:\Maven_workspane\spaceVideo path, execute the command: execute mvn archetype:generate to create a Maven project/module

Note: Creating a web project is: execute the following command, you can just copy and paste it, no modification is required.

mvn archetype:generate -DarchetypeGroupId=org.apache.maven.archetypes -DarchetypeArtifactId=maven-archetype-webapp -DarchetypeVersion=1.4

Then run the command to generate the project:

mvn archetype:generate -DarchetypeGroupId=org.apache.maven.archetypes -DarchetypeArtifactId=maven-archetype-webapp -DarchetypeVersion=1.4

Follow the prompts to perform the following operations:

Define value for property 'groupId': com.rainbowSea.maven
Define value for property 'artifactId': pro02-maven-web
Define value for property 'version' 1.0-SNAPSHOT: :【Enter directly, use the default value】
Define value for property 'package' com.rainbowSea.maven: :【Enter directly, use the default value】
Confirm properties configuration: groupId: com.rainbowSea.maven artifactId:
pro02-maven-web version: 1.0-SNAPSHOT
package: com.rainboweSea.maven Y: :【Enter directly to confirm】

3. Generated pom.xml

As follows in our: E:\Maven_workspane\spaceVideo directory to generate a: pro02-maven-web file.

There is also one: pom.xml the configuration file of the project.

Open it to confirm whether the packaging method is in the form of war package

<packaging>war</packaging>

4. The directory structure of the generated Web project

There is index.jsp under the webapp directory, and web.xml under the WEB-INF directory. It is the same as the directory structure we learned in Tomcat.

5. Create Servlet

①Create a java directory under the main directory

Because our Maven did not automatically create a directory structure corresponding to java for us, we need to create it manually:

Create a java folder

②Create the directory of the package where the Servlet class is located in the java directory

Our path is: E:\Maven_workspane\spaceVideo\ pro02-maven-web\src\main\java\com\rainbowSea\maven

③ Create a Servlet class under the package

package com.rainbowSea.maven; // Note that the package name needs to be written

import javax.servlet.http.HttpServlet;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import javax.servlet.ServletException;
import java.io.IOException;

public class HelloServlet extends HttpServlet{

  protected void doGet(HttpServletRequest request, HttpServletResponse response) throws ServletException, IOException {

    response.getWriter().write("hello maven web");

  }

}

④ Register Servlet in web.xml

Register Servlet in: pro02-maven-web\src\main\webapp\WEB-INF\web.xml

 <servlet>
    <servlet-name>helloServlet</servlet-name>
    <servlet-class>com.rainbowSea.maven.HelloServlet</servlet-class>
  </servlet>
  <servlet-mapping>
    <servlet-name>helloServlet</servlet-name>
    <url-pattern>/helloServlet</url-pattern>
  </servlet-mapping>

6. Write a hyperlink on the index.jsp page

In: E:\Maven_workspane\spaceVideo\pro02-maven-web\src\main\webapp\index.jsp path

<html>
<body>
<h2>Hello World!</h2>
<a href="helloServlet">Access Servlet</a>
</body>
</html>

The full name of JSP is Java Server Page, which, like Thymeleaf, is a server-side page rendering technology. Here we don’t need to care about the details of JSP syntax, just write a hyperlink tag.

7. Compile

At this point, an error occurs when the mvn compile command is executed directly:

The package javax.servlet.http does not exist

Package javax.servlet does not exist

symbol not found

Symbol: class HttpServlet

...

The above error message shows: Our Web project uses the HttpServlet class, and the HttpServlet class belongs to the servlet-api.jar jar package. At this point we say that the Web project needs to rely on the servlet-api.jar package.

8. Configure dependencies on the servlet-api.jar package

For dependencies that do not know the details, you can go to the https://mvnrepository.com/ website to check. Use keywords to search, and then select the appropriate application in the search result list.

For example, we found the dependency information of servlet-api:

The copied information depends on the jar package of javax.servlet, and the coordinates are as follows:.

<!--In order to use HttpServlet normally, you need to import servlet-api dependencies-->
<!-- https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api -->
<dependency>
    <groupId>javax.servlet</groupId>
    <artifactId>javax.servlet-api</artifactId>
    <version>3.1.0</version>
    <scope>provided</scope>
</dependency>

In this way, the above information can be added to pom.xml. Execute the mvn compile command again.

After the configuration is complete, press Ctrl + S to save the following, and we will re-execute mvn compile to compile.

Here we execute:

mvn clean compile # First delete the .class folder target we generated earlier, and then recompile, so that the compiled one is the latest.

9. Package the web project as a war package

Run the mvn package command to generate the war package as shown in the following figure:

mvn package

10. Deploy the war package to run on Tomcat

Copy the war package to the Tomcat server we installed: Tomcat/webapps directory

Start Tomcat:

Try to access through browser: http://localhost:8080/pro02-maven-web/index.jsp

OK, it works fine.

Explanation: The war package we encapsulated has no problem and can be executed normally.
