Microservice environment construction (spring cloud Alibaba) (1)

Modules: Commodity Module, Order Module, User Module

1. 1. Technology selection and preparation

maven: version 3.8.8

Database: MySQL 8.0.32

Persistence layer: springData, jpa

Other java environments: SpringCloud Alibaba technology stack

2. Module design

springcloud- alibaba parent project

shop – common public module [entity class]

shop – user user service [port number: 807x]

shop – product merchandise microservice [port: 808x]

shop – order order microservice [port: 809x]

The simple structure is as follows:

3. A brief introduction to the implementation of microservices

In the microservice architecture, the most common scenario is the mutual call between microservices. In the e-commerce system, it is common for users to place orders to cover up the calls between microservices. The customer wants to initiate a request to place an order with the order microservice. Before saving the order with all your heart, you need to call the product microservice to query product information

Active call: service consumer Passive call: service provider

Two. 1. Create a parent project (remember to check the version)

Corresponding maven dependencies

<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.1.3.RELEASE</version>
    </parent>
    <groupId>com.itheima</groupId>
    <artifactId>springcloud-alibaba</artifactId>
    <version>1.0-SNAPSHOT</version>
    <packaging>pom</packaging>
    <properties>
        <java.version>1.8</java.version>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
        <spring-cloud.version>Greenwich.RELEASE</spring-cloud.version>
        <spring-cloud-alibaba.version>2.1.0.RELEASE</spring-cloud-alibaba.version>
    </properties>
    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
            <dependency>
<!-- Version Correspondence: -->
<!-- 2.3 Create a basic module -->
<!-- 1 Create shop-common module, add dependency in pom.xml -->
                <groupId>com.alibaba.cloud</groupId>
                <artifactId>spring-cloud-alibaba-dependencies</artifactId>
                <version>${spring-cloud-alibaba.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>


</project>

Three. 1. Create a common basic module shop-common

Import the corresponding pom.xml,

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>springcloud-alibaba</artifactId>
        <groupId>com.itheima</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>

    <artifactId>shop-common</artifactId>

    <properties>
        <maven.compiler.source>8</maven.compiler.source>
        <maven.compiler.target>8</maven.compiler.target>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>


        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.76</version>
        </dependency>

        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <version>8.0.32</version>
        </dependency>
    </dependencies>
</project>

as the picture shows:

Create a new com.example.server.pojo package in shop-common

Create entity class user

package com.example.server.pojo;


import lombok.Data;

import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;

@Entity(name = "shop-user")
@Data
public class User {
    @Id
    @GeneratedValue(strategy = GenerationType. IDENTITY)
    private Integer uid;//primary key
    private String username;//username
    private String password;//password
    private String telephone;//Mobile phone number
}

Create entity class Product

package com.example.server.pojo;

import lombok.Data;

import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;

//commodity
@Entity(name = "shop_product")
@Data
public class Product {
    @Id
    // The meaning of the annotation is mainly to generate a uniquely identified primary key for an entity,
    @GeneratedValue(strategy = GenerationType. IDENTITY)
    private Integer pid;//primary key
    private String pname;//product name
    private Double pprice;//commodity price
    private Integer stock;//stock
}

Create entity class Order

package com.example.server.pojo;

import lombok.Data;

import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.GenerationType;
import javax.persistence.Id;

//Order
@Entity(name = "shop_order")
@Data
public class Order {
    @Id
    @GeneratedValue(strategy = GenerationType. IDENTITY)
    private Long oid;//order id
    private Integer uid;//user id
    private String username;//username
    private Integer pid;//commodity id
    private String pname;//product name
    private Double pprice;//Commodity unit price
    private Integer number;//Purchase quantity
}

4. Build user microservice module shop-user

Step: 1 Create a module and import dependencies

Directory Structure:

2 Create SpringBoot main class

package com.example;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class ShopUserApplication {

    public static void main(String[] args) {
        SpringApplication.run(ShopUserApplication.class, args);
    }

}

3 Add configuration file

4 Create the necessary interface and implementation class (controller service dao) Create a new shop-user module, and then perform the following operations 1 Create pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>springcloud-alibaba</artifactId>
        <groupId>com.itheima</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>
    <artifactId>shop-user</artifactId>
    <dependencies>
        <dependency>
            <groupId>com.itheima</groupId>
            <artifactId>shop-common</artifactId>
            <version>1.0-SNAPSHOT</version>
        </dependency>
    </dependencies>
</project>

5. Create a configuration file application.yml

server:
  port: 8071
spring:
  application:
    name: service-product
  datasource:
    driver-class-name: com.mysql.jdbc.Driver
    url: jdbc:mysql:///shop?serverTimezone=UTC &useUnicode=true &characterEncoding=utf-8 &useSSL=true
    username: root
    password: root
  jpa:
    properties:
      hibernate:
        hbm2ddl:
          auto: update
        dialect: org.hibernate.dialect.MySQL5InnoDBDialect

5. Build the product microservice module shop-product

pom.xml file

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>springcloud-alibaba</artifactId>
        <groupId>com.itheima</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>
    <artifactId>shop-product</artifactId>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>com.itheima</groupId>
            <artifactId>shop-common</artifactId>
            <version>1.0-SNAPSHOT</version>
        </dependency>
    </dependencies>
</project>

Write the main class springboot execution class

package com.example;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class ShopProductApplication {

    public static void main(String[] args) {
        SpringApplication.run(ShopProductApplication.class, args);
    }

}

Create a configuration file application.yml

server:
  port: 8081
spring:
  application:
    name: service-product
  datasource:
    driver-class-name: com.mysql.cj.jdbc.Driver
    url: jdbc:mysql:///springcloud_shop?serverTimezone=UTC &useUnicode=true &characterEncoding=utf-8 &useSSL=true
    username: root
    password: 123456
  jpa:
    properties:
      hibernate:
        hbm2ddl:
          auto: update
        dialect: org.hibernate.dialect.MySQL5InnoDBDialect

Create an interface in com.example.productDao

package com.example.dao;

import com.example.server.pojo.Product;
import org.springframework.data.jpa.repository.JpaRepository;

public interface ProductDao extends JpaRepository<Product,Integer> {
}

Create ProductService interface and implementation class

ProductService

package com.example.service;

import com.example.server.pojo.Product;

public interface ProductService {
    Product findByPid(Integer pid);
}

ProductServiceimpl

package com.example.service.impl;

import com.example.dao.ProductDao;
import com.example.server.pojo.Product;
import com.example.service.ProductService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

@Service
public class ProductServiceImpl implements ProductService {
    @Autowired
    private ProductDao productDao;



    @Override
    public Product findByPid(Integer pid) {
        return productDao.findById(pid).get();
    }
}

Create Controller

package com.example.controller;

import com.alibaba.fastjson.JSON;
import com.example.server.pojo.Product;
import com.example.service.ProductService;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RestController;

@RestController
@Slf4j
public class ProductController {
    @Autowired
    private ProductService productService;


    @GetMapping("/product/{pid}")
    public Product product(@PathVariable("pid") Integer pid) {
        Product product = productService.findByPid(pid);
        log.info("Query to product:" + JSON.toJSONString(product));
        return product;
    }

}

Create a MySQL database:

create database springcloud_shop;
use springcloud_shop;


create table shop_product (
pid int ,
pname VARCHAR(10) not NULL,

pprice VARCHAR(10) not null,
stock VARCHAR(10) not null

);

create table shop_user(
uid int not null primary key,
username VARCHAR(20) ,

password VARCHAR(20),

telephone VARCHAR(11)

);
delete from shop_user

create table shop_user (
uid integer not null auto_increment,
userpassword varchar(255),
telephone varchar(255),
username varchar(255),
primary key (uid)

) engine=InnoDB

INSERT INTO shop_product VALUE(1,'Xiaomi','1000','5000');
INSERT INTO shop_product VALUE(2,'Huawei','2000','5000');
INSERT INTO shop_product VALUE(3,'Apple','3000','5000');
INSERT INTO shop_product VALUE(4,'OPPO','4000','5000');

Access the service through a browser localhost:8081/product/1

6. Microservice building order module shop-order

Create a module called shop-order and add springboot dependencies

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>springcloud-alibaba</artifactId>
        <groupId>com.itheima</groupId>
        <version>1.0-SNAPSHOT</version>
    </parent>
    <modelVersion>4.0.0</modelVersion>
    <artifactId>shop-order</artifactId>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>com.itheima</groupId>
            <artifactId>shop-common</artifactId>
            <version>1.0-SNAPSHOT</version>
        </dependency>
    </dependencies>
</project>

Create springboot execution class

package com.example;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class ShopOrderApplication {

    public static void main(String[] args) {
        SpringApplication.run(ShopOrderApplication.class, args);
    }

}

at com.example.serve..dao

OrderDao interface

package com.example.server.dao;

import com.example.server.pojo.Order;
import org.springframework.data.jpa.repository.JpaRepository;

public interface OrderDao extends JpaRepository<Order, Long> {
}

com.example.serve package interface

Order Service

package com.example.server.service;

import com.example.server.pojo.Order;

public interface OrderService {
    void save(Order order);
}

OrderServiceImpl

package com.example.server.service.impl;

import com.example.server.dao.OrderDao;
import com.example.server.pojo.Order;
import com.example.server.service.OrderService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

@Service
public class OrderServiceImpl implements OrderService {
    @Autowired
    private OrderDao orderDao;

    @Override
    public void save(Order order) {
        orderDao. save(order);
    }
}

Create a RestTemplate to call commodity microservices through restTemplate

package com.example;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.context.annotation.Bean;
import org.springframework.web.client.RestTemplate;

@SpringBootApplication
public class OrderApplication {
    public static void main(String[] args) {
        SpringApplication.run(OrderApplication.class, args);
    }
    @Bean
    public RestTemplate getRestTemplate() {
        return new RestTemplate();
    }
}

create controller

package com.example.server.controller;

import com.alibaba.fastjson.JSON;
import com.example.server.pojo.Order;
import com.example.server.pojo.Product;
import com.example.server.service.OrderService;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RestController;
import org.springframework.web.client.RestTemplate;

@RestController
@Slf4j
public class OrderController {
    @Autowired
    private RestTemplate restTemplate;
    @Autowired
    private OrderService orderService;
    //ready to buy 1 item
    @GetMapping("/order/prod/{pid}")
    public Order order(@PathVariable("pid") Integer pid) {
        log.info(">>The customer places an order, at this time, call the product microservice to query product information");
//Call commodity microservices through restTemplate
        Product product = restTemplate.getForObject(
                "http://localhost:8081/product/" + pid, Product.class);
        log.info(">>product information, query result:" + JSON.toJSONString(product));
        Order order = new Order();
        order.setUid(1);
        order.setUsername("Test User");
        order.setPid(product.getPid());
        order.setPname(product.getPname());
        order.setPprice(product.getPprice());
        order. setNumber(1);
        orderService. save(order);
        return order;
    }
}

Visit after starting the service: localhost:8091/order/prod/1

Such a simple microservice environment is set up
