1. Installation
npm i -s vue-drag-resize
2. Use
<template> <div class="screen-content"> <vue-drag-resize w="200" :h="200" @resizing="resize" @dragging="resize" contentClass="resize-box"> <p>{<!-- -->{ top }} х {<!-- -->{ left }}</p> <p>{<!-- -->{ width }} х {<!-- -->{ height }}</p> </vue-drag-resize> </div> </template> <script> import VueDragResize from 'vue-drag-resize' export default { name: 'test', data() { return { width: 0, height: 0, top: 0, left: 0 } }, components: { VueDragResize }, methods: { resize(newRect) { this.width = newRect.width; this.height = newRect.height; this.top = newRect.top; this.left = newRect.left; } } } </script> <style lang="scss" scoped> .screen-content { width: 1280px; height: 720px; position: absolute; top: 100px; left: 100px; background-color: #fff9f5; .resize-box { background-color: skyblue; } } </style>
3. Parameters
Parameters | Description | Type | Default value |
---|---|---|---|
isActive | Is it active | Boolean | false |
isDraggable | Whether dragging is allowed | Boolean | true |
isResizable | Whether scaling is allowed | Boolean | true |
preventActiveBehavior | Whether to disable component behavior by clicking on the component and clicking outside the component area | Boolean | false |
parentW | parent Width, defines the initial width of the parent element, automatically calculated if not specified | Number | 0 |
parentH | Parent height, defines the initial height of the parent element, automatically calculated if not specified | Number | 0 |
parentScaleX | Parent horizontal proportion, defines the initial horizontal proportion of the parent element | Number | 1 |
parentScaleY | Parent vertical proportion, defines the initial vertical proportion of the parent element | Number | 1 |
parentLimitation | Whether it exceeds the parent element and limits the scope of component changes to its parent size, that is Limit the operation component to not exceed the parent element | Boolean | false |
snapToGrid | Whether to move equidistantly, determines whether the component should be moved and resized in predefined steps | Boolean | false |
gridX | X-axis grid step | Number | 50 |
gridY | Y-axis grid step | Number | 50 |
aspectRatio | Whether to scale proportionally | Boolean | false |
x | Positioning horizontal distance | Number | 0 |
y | Positioning vertical distance | Number | 0 |
z | Positioning level | Number | auto |
w | Component width, the value can be a number >= 0 or the string “auto”. If set to “auto”, the initial height value will be equal to the height of the content in the component | Number, String | 200 |
h | Component height, the value can be a number >= 0 or the string “auto”, if set to “auto”, the initial height value will be equal to the component The height of the content | Number, String | 200 |
minw | Minimum width, cannot be set to 0 | Number | 50 |
minh | Minimum height, cannot be set to 0 | Number | 50 |
sticks | Nodes that define the scaling of elements | Array | [‘tl’, ‘tm’, ‘tr’, ‘mr’, ‘br’, ‘bm’, ‘bl’, ‘ml’] |
stickSize | Define the size of the node | Number | 8 |
axis | Allow drag direction | String | x, y , both, none, default both |
dragHandle | The definition should be used for dragging Selector for moving components | String | Example: dragHandle=”.drag” |
dragCancel | Define the selector that should be initialized with drag blocking | String | Example: dragHandle=”.drag” |
contentClass | Define a class that applies to div | String | Example: contentClass=”xxx” |
4. Event
Name | Description | Callback parameters |
---|---|---|
clicked | Component click event | |
activated | Component activation event | |
deactivated | Component deactivation event | |
resizing | Events when zooming |
{ left: Number, top: Number, width: Number, height:Number } |
resizestop | Event when scaling ends | Same as above |
dragging | Drag event | Same as above |
dragstop | Drag end event | Same as above |
