Source: blog.csdn.net/wl_Honest/

article/details/123654621


I have written an article before to record how to simply use scheduled tasks in SpringBoot projects. However, since it requires the use of cron expressions and is defined in advance and placed in the configuration file, the task execution time cannot be dynamically modified while the project is running, which is not very flexible.

After searching and learning on the Internet, I hereby record how to implement dynamic scheduled tasks in the SpringBoot project.

Backend management system + user applet implemented based on Spring Cloud Alibaba + Gateway + Nacos + RocketMQ + Vue & Element, supporting RBAC dynamic permissions, multi-tenancy, data permissions, workflow, three-party login, payment, SMS, mall and other functions

  • Project address: https://github.com/YunaiV/yudao-cloud

  • Video tutorial: https://doc.iocoder.cn/video/

Because it is just a demo, only the required dependencies are introduced:

<dependencies>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-web</artifactId>
    </dependency>

    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-log4j2</artifactId>
        <optional>true</optional>
    </dependency>

    <!-- After spring boot version 2.3, if you need to use verification, you need to manually import the validation package -->
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-validation</artifactId>
    </dependency>

    <dependency>
        <groupId>org.projectlombok</groupId>
        <artifactId>lombok</artifactId>
        <optional>true</optional>
    </dependency>
</dependencies>

Startup class:

package com.wl.demo;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.scheduling.annotation.EnableScheduling;

/**
 * @author wl
 */
@EnableScheduling
@SpringBootApplication
public class DemoApplication {

    public static void main(String[] args) {
        SpringApplication.run(DemoApplication.class, args);
        System.out.println("(*^▽^*)Start successfully!!!(〃'▽'〃)");
    }
}

The configuration file application.yml only defines the service port:

server:
  port: 8089

Scheduled task execution time configuration file: task-config.ini:

printTime.cron=0/10 * * * * ?

Scheduled task execution class:

package com.wl.demo.task;

import lombok.Data;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.PropertySource;
import org.springframework.scheduling.Trigger;
import org.springframework.scheduling.TriggerContext;
import org.springframework.scheduling.annotation.SchedulingConfigurer;
import org.springframework.scheduling.config.ScheduledTaskRegistrar;
import org.springframework.scheduling.support.CronTrigger;
import org.springframework.stereotype.Component;

import java.time.LocalDateTime;
import java.util.Date;

/**
 * Scheduled tasks
 * @author wl
 */
@Data
@Slf4j
@Component
@PropertySource("classpath:/task-config.ini")
public class ScheduleTask implements SchedulingConfigurer {

    @Value("${printTime.cron}")
    private String cron;

    @Override
    public void configureTasks(ScheduledTaskRegistrar taskRegistrar) {
        //Dynamicly use cron expression to set loop interval
        taskRegistrar.addTriggerTask(new Runnable() {
            @Override
            public void run() {
                log.info("Current time: {}", LocalDateTime.now());
            }
        }, new Trigger() {
            @Override
            public Date nextExecutionTime(TriggerContext triggerContext) {
                // Use CronTrigger trigger to dynamically modify cron expressions to operate loop rules
                CronTrigger cronTrigger = new CronTrigger(cron);
                Date nextExecutionTime = cronTrigger.nextExecutionTime(triggerContext);
                return nextExecutionTime;
            }
        });
    }
}

Write an interface so that the execution time of the scheduled task can be dynamically modified by calling the interface:

package com.wl.demo.controller;

import com.wl.demo.task.ScheduleTask;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * @author wl
 */
@Slf4j
@RestController
@RequestMapping("/test")
public class TestController {

    private final ScheduleTask scheduleTask;

    @Autowired
    public TestController(ScheduleTask scheduleTask) {
        this.scheduleTask = scheduleTask;
    }

    @GetMapping("/updateCron")
    public String updateCron(String cron) {
        log.info("new cron :{}", cron);
        scheduleTask.setCron(cron);
        return "ok";
    }
}

Start the project and you can see that the task is executed every 10 seconds:


Access the interface, pass in the request parameter cron expression, and modify the scheduled task to be executed every 15 seconds:


You can see that the task becomes executed every 15 seconds.


In addition to the above method using cron expressions, there is another trigger, which is different from the CronTrigger trigger. This trigger can set the cycle interval time arbitrarily, unlike the cron expression which can only define an interval less than or equal to 59 seconds.

package com.wl.demo.task;

import lombok.Data;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.PropertySource;
import org.springframework.scheduling.Trigger;
import org.springframework.scheduling.TriggerContext;
import org.springframework.scheduling.annotation.SchedulingConfigurer;
import org.springframework.scheduling.config.ScheduledTaskRegistrar;
import org.springframework.scheduling.support.CronTrigger;
import org.springframework.scheduling.support.PeriodicTrigger;
import org.springframework.stereotype.Component;

import java.time.LocalDateTime;
import java.util.Date;

/**
 * Scheduled tasks
 * @author wl
 */
@Data
@Slf4j
@Component
@PropertySource("classpath:/task-config.ini")
public class ScheduleTask implements SchedulingConfigurer {

    @Value("${printTime.cron}")
    private String cron;

    private Long timer = 10000L;

    @Override
    public void configureTasks(ScheduledTaskRegistrar taskRegistrar) {
        //Dynamicly use cron expression to set loop interval
        taskRegistrar.addTriggerTask(new Runnable() {
            @Override
            public void run() {
                log.info("Current time: {}", LocalDateTime.now());
            }
        }, new Trigger() {
            @Override
            public Date nextExecutionTime(TriggerContext triggerContext) {
                // Use CronTrigger trigger to dynamically modify cron expressions to operate loop rules
// CronTrigger cronTrigger = new CronTrigger(cron);
// Date nextExecutionTime = cronTrigger.nextExecutionTime(triggerContext);

                // Using different triggers is the key to setting the cycle time. Different from the CronTrigger trigger, this trigger can set the cycle interval time at will, in milliseconds.
                PeriodicTrigger periodicTrigger = new PeriodicTrigger(timer);
                Date nextExecutionTime = periodicTrigger.nextExecutionTime(triggerContext);
                return nextExecutionTime;
            }
        });
    }
}

Add an interface to modify time:

package com.wl.demo.controller;

import com.wl.demo.task.ScheduleTask;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * @author wl
 */
@Slf4j
@RestController
@RequestMapping("/test")
public class TestController {

    private final ScheduleTask scheduleTask;

    @Autowired
    public TestController(ScheduleTask scheduleTask) {
        this.scheduleTask = scheduleTask;
    }

    @GetMapping("/updateCron")
    public String updateCron(String cron) {
        log.info("new cron :{}", cron);
        scheduleTask.setCron(cron);
        return "ok";
    }

    @GetMapping("/updateTimer")
    public String updateTimer(Long timer) {
        log.info("new timer :{}", timer);
        scheduleTask.setTimer(timer);
        return "ok";
    }
}

Test Results:
