Preface
In this article, we will introduce how to use CUDA-PCL to process point clouds to obtain the best performance. Since PCL cannot fully utilize CUDA on Jetson, NVIDIA has developed some CUDA-based libraries with the same functions as PCL. Code address: https://github.com/NVIDIA-AI-IOT/cuPCL.git (only dynamic libraries and header files, the author said the source code will be open source in the future).
cuPCL contains libraries for processing point clouds using CUDA, as well as examples for their usage. There are several subfolders in the project, each subfolder contains: a library implemented by CUDA and a sample code that uses the library and checks the performance and accuracy by comparing its output with that of PCL. The library supports Xavier, Orin and Linux x86.
about the author
Lei Fan is a senior CUDA software engineer at NVIDIA. He currently works with NVIDIA’s Chinese technical support engineer team to develop solutions for optimizing software performance through CUDA.
Lily Li, is working in developer relations on NVIDIA’s robotics team. She currently works on developing robotics solutions within the Jetson ecosystem to help create best practices.
main content
Many Jetson users choose LiDAR as the main sensor for positioning and perception. LiDAR describes the spatial environment around the vehicle as a set of three-dimensional points, called a point cloud. Point clouds sample the surfaces of surrounding objects and have long-range and high-definition capabilities. The characteristics of accuracy make it very suitable for advanced obstacle perception, map making, positioning and planning algorithms.
In this article, CUDA-PCL 1.0 is introduced. Here we mainly introduce three CUDA-accelerated PCL libraries:
1.CUDA-ICP
2.CUDA-Segmentation
3.CUDA-Filter
CUDA-ICP
In iterative closest point (ICP), a point cloud target or reference point cloud is fixed, while the source points are transformed to best match the reference point. The algorithm iteratively computes the required transformation matrix to minimize the error metric, which is typically the distance from a source point to a reference point cloud, such as the sum of squared differences between matching pairs of coordinates. ICP is one of the widely used algorithms for aligning 3D models given an initial guess pose required by a rigid transformation. The advantages of ICP include high-precision matching results, strong robustness to different initializations, etc. However, it consumes a lot of computing resources. To improve ICP performance on Jetson, NVIDIA has released a CUDA-based ICP that can replace the original ICP version in the Point Cloud Library (PCL). The following code examples are CUDA-ICP examples. This class can be instantiated and then cudaICP.icp() executed directly.
cudaICP icpTest(nPCountM, nQCountM, stream);
icpTest.icp(cloud_source, nPCount,
float *cloud_target, int nQCount,
int Maxiterate, double threshold,
Eigen::Matrix4f &transformation_matrix, stream);
ICP computes the transformation matrix between two point clouds:
source(P)* transformation =target(Q)
Because lidar provides a point cloud with a fixed number, we can get the maximum number of points. Both nPCountM and nQCountM are used to allocate cache for ICP.
class cudaICP
{
public:
/* nPCountM and nQCountM are the maximum of count for input clouds.
They are used to pre-allocate memory.
*/
cudaICP(int nPCountM, int nQCountM, cudaStream_t stream = 0);
~cudaICP(void);
/*
cloud_target = transformation_matrix *cloud_source
When the Epsilon of the transformation_matrix is less than threshold,
the function returns transformation_matrix.
Input:
cloud_source, cloud_target: Data pointer for the point cloud.
nPCount: Point number of the cloud_source.
nQCount: Point number of the cloud_target.
Maxiterate: Threshold for iterations.
threshold: When the Epsilon of the transformation_matrix is less than
threshold, the function returns transformation_matrix.
Output:
transformation_matrix
*/
void icp(float *cloud_source, int nPCount,
float *cloud_target, int nQCount,
int Maxiterate, double threshold,
Eigen::Matrix4f &transformation_matrix,
cudaStream_t stream = 0);
void *m_handle = NULL;
};
Table 2 shows the performance comparison results of CUDA-ICP and PCL-ICP
The state of the point cloud two frames before ICP
The state of the point cloud two frames after ICP
CUDA-Segmentation
The point cloud map contains many ground points, which not only makes the entire map look messy, but also brings trouble to the classification, identification, and tracking of subsequent obstacle point clouds, so they need to be deleted first. Ground removal can be achieved through point cloud segmentation. The library achieves this using Random Sampling Consensus (Ransac) fitting and nonlinear optimization. The following is the sample code for CUDA-Segmentation. First instantiate the class, initialize the parameters, and then call cudaSeg.segment directly to perform ground removal.
//Now Just support: SAC_RANSAC + SACMODEL_PLANE
std::vectorindexV;
cudaSegmentation cudaSeg(SACMODEL_PLANE, SAC_RANSAC, stream);
segParam_t setP;
setP.distanceThreshold = 0.01;
setP.maxIterations = 50;
setP.probability = 0.99;
setP.optimizeCoefficients = true;
cudaSeg.set(setP);
cudaSeg.segment(input, nCount, index, modelCoefficients);
for(int i = 0; i < nCount; i + + )
{
if(index[i] == 1)
indexV.push_back(i);
}
CUDA-Segmentation segments an input with nCount points using some parameters, index is the index of the input, representing the target plane, and modelCoefficients is the coefficient group of the plane.
typedef struct {
double distanceThreshold;
int maxIterations;
double probability;
bool optimizeCoefficients;
} segParam_t;
class cudaSegmentation
{
public:
//Now Just support: SAC_RANSAC + SACMODEL_PLANE
cudaSegmentation(int ModelType, int MethodType, cudaStream_t stream = 0);
~cudaSegmentation(void);
/*
Input:
cloud_in: Data pointer for point cloud
nCount: Count of points in cloud_in
Output:
Index: Data pointer that has the index of points in a plane from input
modelCoefficients: Data pointer that has the group of coefficients of the plane
*/
int set(segParam_t param);
void segment(float *cloud_in, int nCount,
int *index, float *modelCoefficients);
private:
void *m_handle = NULL;
};
Table 3 shows the performance comparison between CUDA-Segmentation and PCL-Segmentation.
Figures 3 and 4 show the raw point cloud data, followed by a processed version that retains only obstacle-related point clouds. This example is typical in point cloud processing, including ground removal, deleting some point clouds and extracting features, and clustering some point clouds.
Figure 3. Original point cloud of CUDA-Segmentation
Figure 4. Point cloud processed by CUDA-Segmentation
CUDA-Filter
Filtering is one of the most important preprocessing operations before segmentation, detection, and recognition of point clouds. Through filtering, the coordinate constraints of the point cloud can be realized, and the X, Y, and Z axes of the point cloud can be directly filtered. Point cloud filtering can only constrain the Z axis or the three coordinate axes X, Y, and Z. CUDA-Filter currently only supports PassThrough, but more methods will be supported in the future. The following is a code example for the CUDA-Filter example that creates an instance of the class, initializes the parameters, and then calls the cudaFilter.filter function directly.
cudaFilter filterTest(stream); FilterParam_t setP; FilterType_t type = PASSTHROUGH; setP.type = type; setP.dim = 2; setP.upFilterLimits = 1.0; setP.downFilterLimits = 0.0; setP.limitsNegative = false; filterTest.set(setP); filterTest.filter(output, & amp;countLeft, input, nCount);
CUDA-Filter uses parameters to filter the input nCount points, and then after filtering by CUDA, outputs results with countLeft points.
typedef struct {
FilterType_t type;
//0=x,1=y,2=z
int dim;
float upFilterLimits;
float downFilterLimits;
bool limitsNegative;
} FilterParam_t;
class cudaFilter
{
public:
cudaFilter(cudaStream_t stream = 0);
~cudaFilter(void);
int set(FilterParam_t param);
/*
Input:
source: data pointer for point cloud
nCount: count of points in cloud_in
Output:
output: data pointer which has points filtered by CUDA
countLeft: count of points in output
*/
int filter(void *output, unsigned int *countLeft, void *source, unsigned int nCount);
void *m_handle = NULL;
};
Table 4. shows the performance comparison between CUDA-Filter and PCL-Filter.
Figures 5 and 6 show examples of PassThrough filters with constraints on the X-axis.
Figure 6. Original point cloud.
Figure 6. Point cloud filtered by constraints on the X-axis.
Comparison with other modules
VoxelGrid
cuOctree
cuCluster
cuNDT
Related Links
https://github.com/NVIDIA-AI-IOT/cuPCL.git
https://developer.nvidia.com/blog/accelerating-lidar-for-robotics-with-cuda-based-pcl/
https://developer.nvidia.com/blog/detecting-objects-in-point-clouds-with-cuda-pointpillars/
