Introduction
This article will introduce a custom CounterView control and show how to create a customizable numeric input control that can set the minimum value, maximum value, step value, and other properties.
Control structure
The CounterView control consists of the following elements:
Decrease button (decreaseButton): used to decrement the value.
Increase button (increaseButton): used to increment the value.
Value edit box (valueEditText): used to display and edit values.
Custom View (customView): used to display custom content (if needed).
Control properties
The CounterView control has the following properties:
Minimum value (minValue): The minimum allowed value of the control value.
Maximum value (maxValue): The maximum allowed value of the control value.
Increment: Controls the step size when increasing or decreasing.
Default value (defaultValue): the initial value of the control.
Decimal place control (decimalEnabled and decimalPlaces): Control whether decimals are allowed to be entered and the limit of decimal places.
Control functions
The CounterView control has the following functions:
Supports increment and decrement operations.
Limits the range of input values to between the minimum and maximum values.
Supports decimal input and can set the number of decimal places as needed.
Provides a listener for value changes, which can perform corresponding operations when the value changes.
main method
The following is a brief description of some important methods in the CounterView control:
| Method | Function |
|---|---|
| init | Initialize each element of the control, including buttons, edit boxes and custom views |
| applyAttributes | Used to apply attributes passed from XML layout |
| setDefaultValue | Set the default value of the control |
| setMinValue | Set the minimum value |
| setMaxValue | Set the maximum value limit |
| setIncrement | Set increment or decrement The step size |
| setValue | Set the value displayed by the control |
| decreaseValue | Decrease the value and limit and prompt according to the set range |
| increaseValue | Increase the value, and limit and prompt according to the set range |
| setDecimalEnabled | Used to enable or disable decimal input and limit it according to the set number of decimal places |
| applyDecimalFilter | Apply a decimal filter to ensure that the entered value meets the set decimal place requirements |
| notifyValueChanged | Notify the listener when the value changes |
| setOnValueChangedListener | Set a listener for value changes to perform corresponding operations when the value changes |
The control code can be modified according to your needs
import android.content.Context;
import android.icu.math.BigDecimal;
import android.text.Editable;
import android.text.InputFilter;
import android.text.InputType;
import android.text.Spanned;
import android.text.TextWatcher;
import android.util.AttributeSet;
import android.view.View;
import android.widget.Button;
import android.widget.EditText;
import android.widget.LinearLayout;
/**
* Copyright (C) 2023-2024 Author
*
* Quantity addition and subtraction controls
* Enter the minus sign in front and the plus sign in the middle
*
* @author xiaolu
* @date 2023/11/8
* @version 1.0.0
*/
public class CounterView extends LinearLayout {
private Button decreaseButton; // decrease button
private Button increaseButton; // Add button
private EditText valueEditText; // Numeric edit box
private View customView; // Custom view
private BigDecimal minValue = BigDecimal.ZERO; // minimum value
private BigDecimal maxValue = BigDecimal.valueOf(100); // maximum value
private BigDecimal increment = BigDecimal.ONE; // step value
private BigDecimal defaultValue = BigDecimal.ZERO; //Default value
private OnValueChangedListener valueChangedListener; // Value change listener
private boolean decimalEnabled = false; // Whether to allow decimals
private int decimalPlaces = 0; // number of decimal places
/**
* Constructor, used to create CustomCounterView instances.
*
* @param context context parameter, cannot be empty
*/
public CounterView(Context context) {
super(context);
init(context);
}
/**
* Constructor, used to create CustomCounterView instances.
*
* @param context context parameter, cannot be empty
* @param attrs attribute parameters
*/
public CounterView(Context context, AttributeSet attrs) {
super(context, attrs);
init(context);
applyAttributes(context, attrs);
}
/**
* Constructor, used to create CustomCounterView instances.
*
* @param context context parameter, cannot be empty
* @param attrs attribute parameters
* @param defStyle default style parameters
*/
public CounterView(Context context, AttributeSet attrs, int defStyle) {
super(context, attrs, defStyle);
init(context);
applyAttributes(context, attrs);
}
//Initialization method
private void init(Context context) {
decreaseButton = new Button(context);
decreaseButton.setText("-");
addView(decreaseButton);
valueEditText = new EditText(context);
valueEditText.setInputType(InputType.TYPE_CLASS_NUMBER);
addView(valueEditText);
increaseButton = new Button(context);
increaseButton.setText(" + ");
addView(increaseButton);
customView = new View(context);
addView(customView);
decreaseButton.setOnClickListener(new OnClickListener() {
@Override
public void onClick(View v) {
decreaseValue();
}
});
increaseButton.setOnClickListener(new OnClickListener() {
@Override
public void onClick(View v) {
increaseValue();
}
});
valueEditText.addTextChangedListener(new TextWatcher() {
@Override
public void beforeTextChanged(CharSequence s, int start, int count, int after) {
}
@Override
public void onTextChanged(CharSequence s, int start, int before, int count) {
try {
BigDecimal currentValue = new BigDecimal(s.toString());
if (currentValue.compareTo(minValue) < 0) {
ToastUtil.showShort("The input number cannot be less than the minimum value" + minValue);
setEditTextValue(minValue.toString());
} else if (currentValue.compareTo(maxValue) > 0) {
ToastUtil.showShort("The input number cannot be greater than the maximum value " + maxValue);
setEditTextValue(maxValue.toString());
}
} catch (NumberFormatException e) {
e.printStackTrace();
}
}
@Override
public void afterTextChanged(Editable s) {
}
});
}
//Apply attribute method
private void applyAttributes(Context context, AttributeSet attrs) {
}
// Set default value method
public void setDefaultValue(BigDecimal defaultValue) {
this.defaultValue = defaultValue;
setValue(defaultValue);
}
//Set the minimum value method
public void setMinValue(BigDecimal minValue) {
this.minValue = minValue;
}
//Set the maximum value method
public void setMaxValue(BigDecimal maxValue) {
this.maxValue = maxValue;
}
// Set step value method
public void setIncrement(BigDecimal increment) {
this.increment = increment;
}
// Get the current value method
public BigDecimal getValue() {
return BigDecimal.ZERO;
}
//Set numerical method
public void setValue(BigDecimal value) {
valueEditText.setText(value.toString());
// Move the cursor to the end of the text
valueEditText.setSelection(valueEditText.getText().length());
}
//Update text data method
private void setEditTextValue(String value) {
valueEditText.setText(value);
// Move the cursor to the end of the text
valueEditText.setSelection(valueEditText.getText().length());
}
// Reduce numerical method
private void decreaseValue() {
try {
String input = valueEditText.getText().toString().trim();
if (!input.isEmpty()) {
BigDecimal currentValue = new BigDecimal(input);
BigDecimal newValue = currentValue.subtract(increment);
if (newValue.compareTo(minValue) < 0) {
ToastUtil.showShort("The input number cannot be less than the minimum value" + minValue);
newValue = minValue;
}
setEditTextValue(newValue.toString());
notifyValueChanged();
}
} catch (NumberFormatException e) {
setEditTextValue("0");
notifyValueChanged();
}
}
// Add numerical method
private void increaseValue() {
try {
String input = valueEditText.getText().toString().trim();
if (!input.isEmpty()) {
BigDecimal currentValue = new BigDecimal(input);
BigDecimal newValue = currentValue.add(increment);
if (newValue.compareTo(maxValue) > 0) {
ToastUtil.showShort("The input number cannot be greater than the maximum value" + maxValue);
newValue = maxValue;
}
setEditTextValue(newValue.toString());
notifyValueChanged();
}
} catch (NumberFormatException e) {
setEditTextValue("0");
notifyValueChanged();
}
}
/**
* Enable decimal input
* @param decimalEnabled Whether to enable on: true off: false
* @param decimalPlaces The number of decimal places is controlled. If it is -1, the number of decimal places is not controlled. Otherwise, it is the number of decimal places.
*/
public void setDecimalEnabled(boolean decimalEnabled, int decimalPlaces) {
this.decimalEnabled = decimalEnabled;
this.decimalPlaces = decimalPlaces;
if (decimalEnabled) {
if (decimalPlaces == -1) {
valueEditText.setInputType(InputType.TYPE_CLASS_NUMBER | InputType.TYPE_NUMBER_FLAG_DECIMAL);
} else {
valueEditText.setInputType(InputType.TYPE_CLASS_NUMBER | InputType.TYPE_NUMBER_FLAG_DECIMAL | InputType.TYPE_NUMBER_FLAG_SIGNED);
}
} else {
valueEditText.setInputType(InputType.TYPE_CLASS_NUMBER);
}
applyDecimalFilter();
}
private void applyDecimalFilter() {
valueEditText.setFilters(new InputFilter[]{new InputFilter() {
@Override
public CharSequence filter(CharSequence source, int start, int end, Spanned dest, int dstart, int dend) {
if (decimalEnabled) {
String value = dest.toString().substring(0, dstart) + source.toString() + dest.toString().substring(dend);
if (!value.isEmpty() & amp; & amp; !value.equals(".") & amp; & amp; !value.equals("-")) {
try {
BigDecimal newValue = new BigDecimal(value);
if (decimalPlaces >= 0 & amp; & amp; newValue.scale() > decimalPlaces) {
return "";
}
} catch (NumberFormatException | ArithmeticException e) {
return "";
}
}
}
return null;
}
}});
}
// Notification value has changed method
private void notifyValueChanged() {
if (valueChangedListener != null) {
valueChangedListener.onValueChanged(new BigDecimal(valueEditText.getText().toString()));
}
}
//Set the value change listener method
public void setOnValueChangedListener(OnValueChangedListener listener) {
this.valueChangedListener = listener;
}
// Numeric change listener interface
public interface OnValueChangedListener {
void onValueChanged(BigDecimal newValue);
}
}
xml reference
<your package name.CounterView
android:id="@ + id/counterView"
android:layout_width="wrap_content"
android:layout_height="wrap_content" />
Set in code
binding.counterView.setMinValue(BigDecimal.ZERO);
binding.counterView.setMaxValue(BigDecimal.TEN);
binding.counterView.setIncrement(BigDecimal.ONE);
binding.counterView.setDefaultValue(BigDecimal.ZERO);
binding.counterView.setDecimalEnabled(true,2);
binding.counterView.setOnValueChangedListener(new CounterView.OnValueChangedListener() {
@Override
public void onValueChanged(BigDecimal newValue) {
//Handle value change events here
Logger.d("CounterViewActivity CounterView onValueChanged data change " + newValue.toString());
}
});
This article introduces the basic structure, functions and usage of the CounterView control, hoping to be helpful to developers when creating customized numeric input controls. By flexibly applying these methods and functions, they can be customized and adjusted according to specific application needs to provide users with a better application experience.
