[Linux System Standard Process Resources] Analysis of the resources required to create the most basic process in Linux, and the differences between thread resources

Directory title

  • Analysis of resources required to create a basic process in Linux
    • 1. Memory resources
    • 2. CPU time
    • 3. File descriptor
    • 4. Process ID and parent process ID
    • 5. Environment variables and command line parameters
    • 6. Kernel data structure
    • 7. Memory usage evaluation
      • 7.1 Basic memory requirements
      • 7.2 Specific values of memory usage
      • 7.3 Process ID (PID)
      • 7.4 File Descriptor
      • 7.5 Summary
  • The difference in resource consumption of threads in processes
  • Conclusion

Analysis of resources required to create a basic process in Linux

Resource Type Description Insights
Memory resources Storage code and data Memory is the basis for the existence of the process
CPU time Execute code CPU time determines the execution speed of the process
File descriptor Identifies files and network connections Files are a way for processes to interact with the outside world
Process ID Uniquely identifies a process Process ID It is the “ID card” of the process
Environment variables Storage configuration information Environment variables affect the behavior of the process

1. Memory resources

When Linux creates a process, it first needs to allocate memory space to store the code, data, heap and stack of the process. These memory areas typically include:

  • Code Segment
  • Data Segment
  • Heap
  • Stack

Code example:

#include <unistd.h>

int main() {<!-- -->
    fork(); // Create a new process
    return 0;
}

2. CPU time

After a process is created, it requires CPU time to execute its code. This involves process scheduling, where the operating system decides which process should use the CPU.

3. File descriptor

Each process has a set of file descriptors that identify open files and network connections.

Code example:

#include <fcntl.h>

int main() {<!-- -->
    int fd = open("file.txt", O_RDONLY); // Open a file
    return 0;
}

4. Process ID and parent process ID

Each process has a unique process ID (PID) and a parent process ID (PPID).

5. Environment variables and command line parameters

The process also needs to store environment variables and command line arguments.

6. Kernel data structure

The operating system kernel maintains some data structures, such as process tables, to track the status of processes.

Source code angle:
In the Linux source code, process creation is mainly implemented through the fork system call, specifically in the do_fork function of the kernel/fork.c file.

7. Memory usage evaluation

7.1 Basic memory requirements

In a Linux system, the memory footprint of a basic process mainly consists of the following parts:

  1. Code Segment: Stores the machine code of the program.
  2. Data Segment: Stores global variables and static variables.
  3. Heap: Dynamically allocated memory space.
  4. Stack: Stores local variables and function call information.
  5. Kernel Stack: Stores the execution information of the process in the kernel state.
  6. Page Table: Stores mapping information from virtual addresses to physical addresses.

7.2 Specific values of memory usage

The specific memory usage value will vary depending on the system and compiler. Generally speaking, the memory footprint of an empty C program on a 64-bit Linux system is approximately as follows:

  • Code snippet: ~4KB
  • Data segment: about 1KB
  • Heap: usually empty initially and allocated on demand
  • Stack: about 8KB (can grow dynamically)
  • Kernel stack: ~8KB
  • Page table: about 4KB

Total: approximately 25KB

Source code angle:
In the Linux source code, the memory layout and allocation of the process are mainly defined in the mm (Memory Management) module. For details, you can view mm/mmap.c and mm/ page_alloc.c file.

7.3 Process ID (PID)

Process ID is usually an integer that uniquely identifies a process. On most Linux systems, this is a 4-byte (32-bit) integer. Therefore, each process’s PID will occupy 4 bytes of memory.

7.4 File Descriptor

A file descriptor (File Descriptor) is a non-negative integer used to identify an open file or other I/O resource. File descriptors are typically stored in a process’s file descriptor table, which is an array structure. Each file descriptor is usually a 4-byte (32-bit) integer.

Assuming that a process has N files open, the size of the file descriptor table is roughly N * 4 bytes.

7.5 Summary

Resource type Memory usage Description
Code segment, data segment, heap and stack Several KB to several MB Storage program code and data
Process ID (PID) 4 bytes Uniquely identifies a process
File descriptor N * 4 bytes Identifies open files and network connections
Kernel data structure Dozens to hundreds of bytes Storage process status, scheduling information, etc.

This table summarizes the memory resources required to create a basic process in Linux. In general, at least a few KB of memory is required. This does not include other types of resources such as CPU time, environment variables, etc. I hope this summary can answer your questions more accurately.

The difference in resource consumption of threads in processes

The main differences between threads and processes are as follows in terms of memory and resource usage:

  1. Shared resources: Threads share the same address space, code segments, data segments, open files, etc., so there is no need to allocate independent memory for these like processes.

  2. Stack space: Each thread has its own stack space, which is their main memory overhead.

  3. Kernel data structures: Threads typically have fewer kernel data structures, which means they are usually more lightweight than processes.

  4. File descriptors: Threads usually share the same set of file descriptors, while processes have their own independent file descriptors.

  5. Register state: Each thread has its own register state, but this is usually less than the process’s register state.

Overall, threads generally save more memory and other resources than processes, which is why threads are often more popular in applications that require high concurrency.

Resource Type Process Thread Description
Code segment, data segment Independent Shared Store the code and data of the program
Heap Independent Shared Dynamically allocated memory space
Stack Independent Independent Store local variables and function call information
Process/thread ID 4 bytes 4 bytes Uniquely identifies a process or thread
File descriptor Independent Shared Identifies open files and network connections
Kernel data structures Independent Less Storage process/thread status, scheduling information, etc.
Register status Independent Independent Storing CPU register status

From this table you can see:

  • Threads share code segments, data segments, and heaps with processes, which reduces memory usage.
  • Threads have their own independent stack and register state, but are generally more lightweight than processes.
  • Threads share file descriptors, while processes have their own.

This should more clearly demonstrate the difference in resource usage between threads and processes. I hope this time I can answer your questions.
